- Hot-Pluggable SFP Footprint
- Supports upto 3.072Gbps Data Rates
- Single 3.3V Power Supply and Industry Low Power dissipation
- Max link lenght Up to 5KM on SMF Fiber
- Class 1 Laser Safety Compliant
- RoHS 6 compliant (lead free)
- Operating Case Temperature : 0~70℃ (Extended /Industrial grade optional)
- Compliant with SFP MSA Specification
- Low power consumption
| P/N | JP-B353G-FL5D |
| Form Factor | SFP |
| Standard & protocal | 3GBASE BX |
| Data Rate | 3.072Gbps |
| WaveLength | TX1310/RX1550nm |
| Media | SMF |
| Reach | 5KM |
| Interface | Simplex LC |
| Tx Source | FP |
| Rx Source | PIN |
| Tx Power | -10～-3dBm |
| Rx Power | ≦-18dBm |
| Temp. | Tc/Ti |
| P/N | DataRate/Protocol | WaveLength | Reach | Interface | Media | Tx Power | Rx Power | Temp. |
|---|---|---|---|---|---|---|---|---|
| JP-B353G-FL5D | 3.072Gbps | TX1310/RX1550nm More | 5KM | Simplex LC | SMF | -10～-3dBm | ≦-18dBm | Tc/Ti |
| JP-B533G-DL5D | 3.072Gbps | TX1550/RX1310nm More | 5KM | Simplex LC | SMF | -10～-3dBm | ≦-18dBm | Tc/Ti |
| JP-B353G-DL20D | 3.072Gbps | TX1310/RX1550nm More | 20KM | Simplex LC | SMF | -5～0dBm | ≦-18dBm | Tc/Ti |
| JP-B533G-DL20D | 3.072Gbps | TX1550/RX1310nm More | 20KM | Simplex LC | SMF | -5～0dBm | ≦-18dBm | Tc/Ti |
