- Hot-Pluggable SFP28 Footprint
- Supports upto 25Gbps Data Rates
- Single 3.3V Power Supply and Industry Low Power dissipation
- Max link lenght Up to 10KM on SMF Fiber
- Class 1 Laser Safety Compliant
- RoHS 6 compliant (lead free)
- Operating Case Temperature : 0~70℃ (Extended /Industrial grade optional)
- Compliant with SFP28 MSA Specification
- Low power consumption
| P/N | JP28-Cxx25G-DL10D |
| Form Factor | SFP28 |
| Standard & protocal | 25GBASE CWDM |
| Data Rate | 25Gbps |
| WaveLength | CWDM 1270nm~1370nm |
| Media | SMF |
| Reach | 10KM |
| Interface | Duplex LC |
| Tx Source | DFB |
| Rx Source | PIN |
| Tx Power | 0～+6.0dBm |
| Rx Power | ≦-14.0dBm |
| Temp. | Tc/Ti |
| P/N | DataRate/Protocol | WaveLength | Reach | Interface | Media | Tx Power | Rx Power | Temp. |
|---|---|---|---|---|---|---|---|---|
| JP28-Cxx25G-DL10D | 25Gbps | CWDM 1270nm~1370nm More | 10KM | Duplex LC | SMF | 0～+6.0dBm | ≦-14.0dBm | Tc/Ti |
| JP28-Cxx25G-EL10D | 25Gbps | CWDM 1470nm~1570nm More | 10KM | Duplex LC | SMF | -3.0～+6.0dBm | ≦-12.0dBm | Tc/Ti |
