- Hot-Pluggable SFP Footprint
- Supports upto 622Mbps Data Rates
- Single 3.3V Power Supply and Industry Low Power dissipation
- Max link lenght Up to 20KM on SMF Fiber
- Class 1 Laser Safety Compliant
- RoHS 6 compliant (lead free)
- Operating Case Temperature : 0~70℃ (Extended /Industrial grade optional)
- Compliant with SFP MSA Specification
- Low power consumption
| P/N | JP-1312-FL20D |
| Form Factor | SFP |
| Standard & protocal | 622MBASE LX |
| Data Rate | 622Mbps |
| WaveLength | 1310nm |
| Media | SMF |
| Reach | 20KM |
| Interface | Duplex LC |
| Tx Source | FP |
| Rx Source | PIN |
| Tx Power | -15～-8dBm |
| Rx Power | ≦-28dBm |
| Temp. | Tc/Ti |
| P/N | DataRate/Protocol | WaveLength | Reach | Interface | Media | Tx Power | Rx Power | Temp. |
|---|---|---|---|---|---|---|---|---|
| JP-1312-FL20D | 622Mbps | 1310nm More | 20KM | Duplex LC | SMF | -15～-8dBm | ≦-28dBm | Tc/Ti |
| JP-1312-FL40D | 622Mbps | 1310nm More | 40KM | Duplex LC | SMF | -3～+2dBm | ≦-28dBm | Tc/Ti |
| JP-1312-DL80D | 622Mbps | 1550nm More | 80KM | Duplex LC | SMF | -3～+2dBm | ≦-28dBm | Tc/Ti |
