- Hot-Pluggable QSFP28 Footprint
- Supports upto 50Gbps Data Rates
- Single 3.3V Power Supply and Industry Low Power dissipation
- Max link lenght Up to 10KM on SMF Fiber
- Class 1 Laser Safety Compliant
- RoHS 6 compliant (lead free)
- Operating Case Temperature : 0~70℃ (Extended /Industrial grade optional)
- Compliant with QSFP28 MSA Specification
- Low power consumption
| P/N | JQ28-B2350G-DL10D |
| Form Factor | QSFP28 |
| Standard & protocal | 50GBASE BX |
| Data Rate | 50Gbps |
| WaveLength | 1270nm&1330nm |
| Media | SMF |
| Reach | 10KM |
| Interface | Duplex LC |
| Tx Source | DML |
| Rx Source | PIN |
| Tx Power | -4.5～+4.2dBm |
| Rx Power | ≦-8.4dBm |
| Temp. | Tc |
| P/N | DataRate/Protocol | WaveLength | Reach | Interface | Media | Tx Power | Rx Power | Temp. |
|---|---|---|---|---|---|---|---|---|
| JQ28-B2350G-DL10D | 50Gbps | 1270nm&1330nm More | 10KM | Duplex LC | SMF | -4.5～+4.2dBm | ≦-8.4dBm | Tc |
| JQ28-1350G-DL10D | 50Gbps | 1310nm More | 10KM | Duplex LC | SMF | -4.5～+4.2dBm | ≦-8.4dBm | Tc |
| JQ28-1350G-DL40D | 50Gbps | 1310nm More | 40KM | Duplex LC | SMF | +0.4～+6.6dBm | ≦-15.1dBm | Tc |
