- Hot-Pluggable SFP28 Footprint
- Supports upto 25Gbps Data Rates
- Single 3.3V Power Supply and Industry Low Power dissipation
- Max link lenght Up to 10KM on SMF Fiber
- Class 1 Laser Safety Compliant
- RoHS 6 compliant (lead free)
- Operating Case Temperature : 0~70℃ (Extended /Industrial grade optional)
- Compliant with SFP28 MSA Specification
- Low power consumption
| P/N | JP28-B2325G-DL10D |
| Form Factor | SFP28 |
| Standard & protocal | 25GBASE BX |
| Data Rate | 25Gbps |
| WaveLength | 1270nm&1330nm |
| Media | SMF |
| Reach | 10KM |
| Interface | Simplex LC |
| Tx Source | DFB |
| Rx Source | PIN |
| Tx Power | -2.0～+4.0dBm |
| Rx Power | ≦-13.0dBm |
| Temp. | Tc/Ti |
| P/N | DataRate/Protocol | WaveLength | Reach | Interface | Media | Tx Power | Rx Power | Temp. |
|---|---|---|---|---|---|---|---|---|
| JP28-B2325G-DL10D | 25Gbps | 1270nm&1330nm More | 10KM | Simplex LC | SMF | -2.0～+4.0dBm | ≦-13.0dBm | Tc/Ti |
| JP28-B3225G-DL10D | 25Gbps | 1330nm&1270nm More | 10KM | Simplex LC | SMF | -2.0～+4.0dBm | ≦-13.0dBm | Tc/Ti |
| Datasheet | Download |
| Manual | Download |
| Software | Download |
