CFP4 103.1~112Gbps 850nm MMF 100M MPO Optical Transceiver

JCP4-85100GX-VM01D is a MSA compliant 103.1~112Gbps CFP/CFP2/CFP4 Packaged Transceiver. It is designed,assembled,tested in the ISO certified manufacturing facilities and an ideal choice to fulfill various optical Networking applications.

  • more
  • Hot-Pluggable CFP4 Footprint
  • Supports upto 103.1~112Gbps Data Rates
  • Single 3.3V Power Supply and Industry Low Power dissipation
  • Max link lenght Up to 100M on MMF Fiber
  • Class 1 Laser Safety Compliant
  • RoHS 6 compliant (lead free)
  • Operating Case Temperature : 0~70℃ (Extended /Industrial grade optional)
  • Compliant with CFP4 MSA Specification
  • Low power consumption

P/N JCP4-85100GX-VM01D
Form Factor CFP4
Standard & protocal 100GBASE SR4
Data Rate 103.1~112Gbps
WaveLength 850nm
Media MMF
Reach 100M
Interface MPO
Tx Source VCSEL
Rx Source PIN
Tx Power -8.4~+2.4dBm
Rx Power ≦-9.2dBm
Temp. Tc
P/N DataRate/Protocol WaveLength Reach Interface Media Tx Power Rx Power Temp.
JCP4-85100GX-VM01D 103.1~112Gbps 850nm  More 100M MPO MMF -8.4~+2.4dBm ≦-9.2dBm Tc
JCP4-L100GX-DL10D 103.1~112Gbps LAN-WDM 1294nm~1310nm  More 10KM Duplex LC SMF -4.3~+4.5dBm ≦-8.6dBm Tc
