- Hot-Pluggable SFP+ Footprint
- Supports upto 28Gbps Data Rates
- Single 3.3V Power Supply and Industry Low Power dissipation
- Max link lenght Up to 10KM on SMF Fiber
- Class 1 Laser Safety Compliant
- RoHS 6 compliant (lead free)
- Operating Case Temperature : 0~70℃ (Extended /Industrial grade optional)
- Compliant with SFP+ MSA Specification
- Low power consumption
| P/N | JPP-1328G-DL10D |
| Form Factor | SFP+ |
| Standard & protocal | 32GBASE LW |
| Data Rate | 28Gbps |
| WaveLength | 1310nm |
| Media | SMF |
| Reach | 10KM |
| Interface | Duplex LC |
| Tx Source | DFB |
| Rx Source | PIN |
| Tx Power | -7～2dBm |
| Rx Power | ≦-11.6dBm |
| Temp. | Tc |
| P/N | DataRate/Protocol | WaveLength | Reach | Interface | Media | Tx Power | Rx Power | Temp. |
|---|---|---|---|---|---|---|---|---|
| JPP-1328G-DL10D | 28Gbps | 1310nm More | 10KM | Duplex LC | SMF | -7～2dBm | ≦-11.6dBm | Tc |
| JPP-8528G-VL01D | 28Gbps | 850nm More | 100M | Duplex LC | MMF | -6.2～2dBm | ≦-10.2dBm | Tc |
| Datasheet | Download |
| Manual | Download |
| Software | Download |
