- Hot-Pluggable SFP Footprint
- Supports upto 10/100/1000Mbps Data Rates
- Single 3.3V Power Supply and Industry Low Power dissipation
- Max link lenght Up to 100M on Copper Cable Fiber
- Class 1 Laser Safety Compliant
- RoHS 6 compliant (lead free)
- Operating Case Temperature : 0~70℃ (Extended /Industrial grade optional)
- Compliant with SFP MSA Specification
- Low power consumption
| P/N | JP-AND-T01-TDRL |
| Form Factor | SFP |
| Standard & protocal | 10/100/1000BASE T |
| Data Rate | 10/100/1000Mbps |
| WaveLength | / |
| Media | Copper Cable |
| Reach | 100M |
| Interface | RJ45 |
| Tx Source | / |
| Rx Source | / |
| Tx Power | / |
| Rx Power | / |
| Temp. | Tc/Ti |
| Rx_LOS | YES |
| Tx Disable | YES |
| P/N | DataRate/Protocol | WaveLength | Reach | Interface | Media | Tx Power | Rx Power | Temp. |
|---|---|---|---|---|---|---|---|---|
| JP-AND-T01-TDRL | 10/100/1000Mbps | / More | 100M | RJ45 | Copper Cable | / | / | Tc/Ti |
| JP-AND-T01-TD | 10/100/1000Mbps | / More | 100M | RJ45 | Copper Cable | / | / | Tc/Ti |
| JP-AND-T01-RL | 10/100/1000Mbps | / More | 100M | RJ45 | Copper Cable | / | / | Tc/Ti |
| Datasheet | Download |
| Manual | Download |
| Software | Download |
