- Hot-pluggable form-factor connectors
- Supports upto 100G to 4x25G Data Rates
- Single 3.3V Power Supply and Industry Low Power dissipation
- Max link length Up to xxM(Custom Length) on OM3/OM4 Cable
- RoHS Compliant (lead free)
- Operating Case Temperature : 0~70℃
- Compliant with QSFP28 to 4SFP28 MSA Specification
- Low power consumption
| P/N | JAC-QP28V4P28-xxM |
| Data Rate | 100G to 4x25G |
| Media | OM3/OM4 |
| Formfactor | QSFP28 to 4SFP28 |
| Cable Type | Active |
| AWG | n/a |
| Length | xxM(Custom Length) |
| Opterating Temp. | 0~70℃ |
| P/N | DataRate/Protocol | Media | Formfactor | Cable Type | AWG | Length | Opterating Temp. |
|---|---|---|---|---|---|---|---|
| JAC-QP28V4P28-xxM | 100G to 4x25G | OM3/OM4 More | QSFP28 to 4SFP28 | Active | n/a | xxM(Custom Length) | 0~70℃ |
| JAC-QP28V4P28-1M | 100G to 4x25G | OM3/OM4 More | QSFP28 to 4SFP28 | Active | n/a | 1M | 0~70℃ |
| JAC-QP28V4P28-2M | 100G to 4x25G | OM3/OM4 More | QSFP28 to 4SFP28 | Active | n/a | 2M | 0~70℃ |
| JAC-QP28V4P28-3M | 100G to 4x25G | OM3/OM4 More | QSFP28 to 4SFP28 | Active | n/a | 3M | 0~70℃ |
| JAC-QP28V4P28-5M | 100G to 4x25G | OM3/OM4 More | QSFP28 to 4SFP28 | Active | n/a | 4M | 0~70℃ |
